Animated LEDs

Animated LEDs contain a tiny integrated circuit (IC) built directly into the LED package that drives automatic flashing, flickering, fading, or…

Read full description & FAQ ↓

Items 1-36 of 74

Animated LEDs contain a tiny integrated circuit (IC) built directly into the LED package that drives automatic flashing, flickering, fading, or color-alternating sequences with zero external components beyond a standard current-limiting resistor. No Arduino, no 555 timer, no microcontroller, no code — just apply DC power through a resistor and the animation runs on its own, indefinitely, from the moment the circuit is energized. That simplicity makes animated LEDs the go-to solution for model railroaders, prop builders, holiday lighting designers, escape room creators, scale model hobbyists, and anyone who needs eye-catching movement without programming or timing circuits. We stock animated LEDs in four through-hole sizes — 1.8mm, 3mm, 5mm, and 10mm — plus surface-mount SMD packages in 0603 and 0807 sizes, across seven distinct animation types and dozens of color options.

Animation types explained: We carry seven animation patterns, each driven by a different IC program inside the LED. Slow flash (1Hz) blinks once per second — the classic railroad crossing signal cadence, also widely used for alarm panel indicators, turn signal mockups, and safety marker lights. Fast flash (2Hz) blinks twice per second for a more urgent, attention-grabbing effect suited to bicycle safety lights, construction barricade flashers, and warning beacons. Extra-fast flash (6Hz) produces a rapid strobe at six flashes per second, mimicking emergency vehicle light bars for police car models, fire truck builds, and ambulance dioramas, as well as arcade machine attract modes and rave party effects. Extra-slow flash (0.25Hz) blinks once every four seconds — the subtle, unhurried pulse of a MacBook sleep indicator or standby light, perfect for fairy light accents and gentle ambient markers. Flickering candle LEDs use a randomized algorithm to simulate the organic, irregular dance of a real candle flame — the single most popular animated LED type for Christmas light string replacements, jack-o-lantern illumination, fireplace log props, campfire dioramas, medieval and fantasy terrain builds, and restaurant table candle substitutes. Fading / breathing LEDs smoothly ramp brightness up and down in a continuous cycle, producing the pulsing “breathing” glow made famous by Apple laptop sleep indicators — widely used for sci-fi prop consoles, KITT-style scanning effects, ambient mood lighting, and heartbeat monitor simulations. Red/blue alternating LEDs contain two separate dies (one red, one blue) that switch back and forth automatically, producing the unmistakable police/emergency vehicle strobe pattern used in scale model squad cars, security deterrent lights, and patriotic displays.

Use cases — model railroading: Animated LEDs solve dozens of common model railroad lighting challenges without a single line of DCC decoder programming. A pair of red 1Hz slow-flash LEDs replicates a grade crossing signal that alternates left-right when wired with opposite polarity leads (one LED lights while the other is dark on each half-cycle of a simple astable circuit, or simply wire two self-flashing LEDs since their internal ICs naturally drift out of sync to create an alternating appearance). Amber 0.25Hz extra-slow LEDs simulate the lazy blink of a yard warning beacon. Flickering candle LEDs in warm white or amber recreate the coal-fire glow inside a steam locomotive firebox, the flicker of an oil lamp on a station platform, or a campfire scene at a hobo jungle. Breathing LEDs in green simulate the pulsing status light on a modern diesel locomotive control stand. Fast-flash red LEDs at 2Hz simulate the rapid blink of end-of-train devices (ETDs/FREDs). The 1.8mm and 3mm sizes are scale-appropriate for N and HO layouts, while 5mm and 10mm suit O and G scale. For DCC or AC track power, add a bridge rectifier and smoothing capacitor — see the AC/DCC wiring guide.

Use cases — holiday, prop, and hobby: Flickering candle LEDs are among our best sellers during the holiday season because they drop directly into Christmas string light sockets (the 5mm concave flat-top shape is a dimensional match for standard C7 and C9 replacement bulbs) and produce a realistic warm-glow flicker without fire risk. Jack-o-lantern builders use amber or orange flickering LEDs to replace tea lights inside carved pumpkins. Escape room designers wire 6Hz strobe LEDs behind translucent panels to create urgency during countdown sequences. Haunted house builders use red flickering LEDs behind fabric flames and green breathing LEDs inside bubbling cauldron props. Cosplay and prop makers embed breathing blue LEDs in Iron Man arc reactor builds and fading white LEDs in sci-fi control panels. Warhammer 40K and miniature wargaming painters wire 1.8mm and 3mm flickering LEDs into Dreadnought weapon barrels for muzzle flash effects and into terrain pieces for burning wreckage. Guitar pedal builders sometimes use slow-flash LEDs as a visual metronome or tap-tempo indicator in stompbox builds.

Electrical characteristics: Animated LEDs have the same forward voltage ranges as their static counterparts: red/orange/yellow/amber ≈ 2.0–2.2V; blue/green/white ≈ 3.0–3.2V. Maximum forward current is 20mA. The built-in IC consumes a negligible amount of the drive current — brightness is virtually identical to a standard LED of the same color and size. Every animated LED requires a series current-limiting resistor just like any other bare LED. Use our LED resistor calculator to find the correct value for your supply voltage and LED color. At 12V, a 510Ω resistor works for red and a 470Ω resistor works for blue/green/white. At 5V (Arduino), use 150Ω for red or 100Ω for white/blue. If you prefer zero wiring, browse our animated pre-wired LEDs — the resistor is already soldered to the lead wire for plug-and-play operation at your chosen voltage. New to LEDs entirely? Pre-wired LEDs are the easiest starting point — the resistor is already built in, so you just connect power and ground.

Sizes available: We stock animated LEDs in six package sizes. 1.8mm (micro T-1) is the smallest through-hole option, ideal for N and Z scale model railroad applications and miniature wargaming terrain where even a 3mm body would be oversized. 3mm (T-1) fits HO scale locomotive headlight housings, signal heads, and guitar pedal enclosures with 3mm bezel holes. 5mm (T-1¾) is the most popular size overall, compatible with standard 5mm LED holders, breadboard prototyping, and the widest range of project enclosures. 10mm provides a large, visually prominent indicator for G scale railroad signals, control panels, and decorative displays. 0807 SMD and 0603 SMD are surface-mount packages for PCB-based designs, custom LED strips, and ultra-compact builds where through-hole leads are not practical. Browse by size and animation type using the subcategories below.

Related categories: For static (non-animated) LEDs, browse clear top DIP LEDs and diffused LEDs. For multi-color mixing under your own control, see RGB LEDs. For surface-mount animated options, check our SMD LED subcategories. For 12V circuits without resistor calculations, see 12V built-in resistor LEDs. For ready-to-install animated LEDs with the resistor pre-soldered to the wire, browse animated pre-wired LEDs.

Yes. Animated LEDs have the same electrical requirements as standard LEDs — they need a series current-limiting resistor between the power supply and the LED. The built-in animation IC does not regulate current. Without a resistor, the LED will draw excessive current and burn out immediately. Use our LED resistor calculator to find the correct value for your supply voltage. If you want zero-math installation, our animated pre-wired LEDs include the resistor on the wire.
Each animated LED contains a tiny integrated circuit (IC) bonded directly to the LED die inside the epoxy package. This IC includes an oscillator and driver circuit that automatically switches the LED on and off (or ramps brightness up and down for fading types) at a fixed, factory-programmed rate. The animation starts the instant DC power is applied and runs continuously as long as power is present. No code, no programming, no external timer circuit — just a resistor and a DC power source.
No. The animation pattern and rate are permanently programmed into the IC at the factory and cannot be modified. This is actually an advantage for most applications — the timing is rock-solid and never drifts, unlike software-based approaches that can glitch or require maintenance. If you need a different flash rate, simply choose the appropriate animated LED: 0.25Hz for extra slow, 1Hz for slow, 2Hz for fast, or 6Hz for extra fast. For fully custom patterns, use a standard static LED driven by an Arduino or 555 timer circuit instead.
Yes, but animated LEDs require DC power, so you need to convert DCC track voltage (which is a form of AC) to DC first. Add a bridge rectifier and a smoothing capacitor between the track bus and your LED circuit. The same applies to 12V AC landscape transformers. See our AC/DCC wiring guide for a complete diagram with component values. Once you have clean DC, the animated LED works exactly as it would on any other DC power source.
When first powered on simultaneously, two identical animated LEDs will start roughly in sync. Over time, tiny manufacturing variations in the internal oscillator cause them to drift slightly out of phase. For railroad crossing signals this is actually desirable — the natural drift creates a realistic alternating left-right flash pattern without any special wiring. If you need precise synchronization, use standard static LEDs driven by a shared external oscillator (Arduino, 555 timer, or dedicated flasher IC).
Flickering candle LEDs use a pseudo-random algorithm that varies brightness erratically — quick jumps between dim and bright with unpredictable timing, mimicking the way a real candle flame dances in air currents. The effect is organic and irregular. Fading (breathing) LEDs use a smooth, repeating ramp: brightness gradually increases to full, then gradually decreases to near-off, then repeats. The cycle is perfectly regular and predictable, like the sleep indicator light on a laptop. Choose flickering for fire and flame simulations; choose fading for electronic standby indicators, ambient mood lighting, and sci-fi prop effects.
