1206 SMD Red - Ultra Bright LED
In stock
- SKU
- 1206SMDRED
- Color
- Red
- Size
- 1206 SMD
- Buy 50 for $0.19 each and save 5%
- Buy 100 for $0.18 each and save 10%
- Buy 250 for $0.17 each and save 15%
- Buy 500 for $0.16 each and save 20%
- Buy 1000 for $0.15 each and save 25%
Description / 1206 SMD Red - Ultra Bright LED
The 1206 Red SMD LED (3.2 × 1.6mm, metric 3216) is the largest and easiest surface-mount LED to hand-solder — generous pads, forgiving with tweezers, and compatible with SMD-to-DIP breadboard adapters. The best starting point if you’re new to SMD work. Red is the standard power-on and fault indicator color — immediately readable on any finished board.
| Package | 1206 (3216 metric) — SMD surface mount |
| Forward Voltage | 1.8-2.2v |
| Brightness | 120mcd |
| Viewing Angle | 120 Degrees |
| Lens | Clear |
| Drive Current | 20mA typical |
The easiest SMD to hand-solder. Large pads, forgiving with tweezers, and compatible with SMD-to-DIP breadboard adapters.
Common uses:
- Automotive instrument cluster repair — some 1990s–2000s vehicles use 1206 indicators on cluster PCBs
- Model railroad DCC decoder lighting — hand-soldering friendly for adding headlights and function LEDs to decoders (SBS4DCC community)
- Eurorack synthesizer and audio electronics — indicator LEDs on modular synth panels and audio PCBs
- Student and beginner SMD projects — the forgiving pad size makes this ideal for learning reflow and hand-soldering techniques
- Gaming console and controller modding — status indicator mods and accent lighting
Also available: 0805 (smaller)
Sold individually (1 LED per quantity ordered).
More Information
| Size | 1206 SMD |
|---|---|
| Color | Red |
| Luminosity/Brightness | 120 mcd |
| Forward Voltage | 1.8-2.2v |
| Current | 20mA |
| Wavelength | 625-630 nm |
| Viewing Angle | 120 Degrees |
| Mount Style | SMD (Surface Mount Diode) |
| Lens Color | Clear |
| LED Brightness Class | Super/Ultra/Extreme |
| Documentation Link | Documentation: 1206 SMD Red - Ultra Bright LED Datasheet / Specifications |
