1 Watt High Power Star LED - Green
In stock
- SKU
- 1WATTSTARLEDGREEN
- Color
- Pure Green
- Size
- 1W Star LED
Description / 1 Watt High Power Star LED - Green
The 1 Watt Star Pure Green High Power LED delivers significantly more output than standard 20mA indicator LEDs — built for applications where brightness matters: flashlight builds, grow lights, reef aquarium fixtures, stage lighting, and DIY fishing lights.
Green penetrates water better than any other color — the proven wavelength for attracting fish. DIY dock and boat fishing lights are a major use case.
| Type | 1 Watt Star |
| Forward Voltage | 3.2-3.6v |
| Brightness | 100 lm (Lumens) |
| Viewing Angle | 140 Degrees |
| Drive Current | 350mA |
| Power | 1 Watt |
Mounting: Mounted on a 20mm aluminum star PCB for heatsinking. Solder or thermal-adhesive to an aluminum heatsink — active cooling (fan) recommended above 1W continuous.
Common applications
- Primary: DIY fishing lights (green 520–530nm penetrates water most efficiently, attracting phytoplankton then baitfish then game fish — The Hull Truth, Crappie.com), stage lighting (green channel for RGB par cans)
- DIY flashlight modification: Replace or upgrade the emitter in Convoy S2+, Emisar D4V2, Noctigon, Maglite, and P60 drop-in hosts. The flashlight modding community (BudgetLightForum, CandlePowerForums, r/flashlight) is the largest buyer of individual high-power star LEDs.
- Stage and theatrical lighting: Build RGBW par cans and spot fixtures with individually driven color channels. DMX-controllable with constant-current drivers.
- Machine vision and inspection: High-power illumination for camera inspection systems, UV fluorescence inspection, and industrial quality control.
Power and thermal management
These LEDs come pre-mounted on a 20mm aluminum star PCB that acts as a heatsink. For most applications the star PCB provides sufficient thermal management on its own — no additional heatsink is required for typical duty cycles. For continuous high-duty-cycle applications (e.g. grow light arrays running 12+ hours), mounting the star to an aluminum surface improves heat dissipation. Use a constant-current LED driver (Meanwell LDD series, BuckPuck) rather than a simple resistor — constant-current drivers maintain consistent brightness and prevent thermal runaway.
Pair with
- Power supplies — constant-current LED drivers (Meanwell LDD recommended)
- TIR optics / reflectors — focus or spread the beam for your application (60° for flood, 15° for throw)
Frequently Asked Questions
Sold individually (1 LED per quantity ordered).
More Information
| Size | 1W Star LED |
|---|---|
| Color | Pure Green |
| Luminosity/Brightness | 100 lm (Lumens) |
| Forward Voltage | 3.2-3.6v |
| Current | 350mA |
| Wavelength | 520-530nm |
| Viewing Angle | 140 Degrees |
| Mount Style | Surface Mount |
| Lens Color | Clear |
| LED Brightness Class | Super/Ultra/Extreme |
| Documentation Link | Documentation: 1 Watt High Power Star LED - Pure Green Datasheet / Specifications |
