0603 SMD Yellow / Gold - Ultra Bright LED
In stock
- SKU
- 0603SMDYELLOW
- Color
- Yellow/Gold
- Size
- 0603 SMD
- Buy 50 for $0.19 each and save 5%
- Buy 100 for $0.18 each and save 10%
- Buy 250 for $0.17 each and save 15%
- Buy 500 for $0.16 each and save 20%
- Buy 1000 for $0.15 each and save 25%
Description / 0603 SMD Yellow / Gold - Ultra Bright LED
The 0603 Yellow SMD LED (1.6 × 0.8mm, metric 1608) is the most widely used SMD indicator size in both hobbyist and production PCB work — small enough for tight layouts, large enough to hand-solder reliably with flux and a fine-tip iron. Yellow is the classic turn signal and caution indicator color — matches automotive and vintage equipment lighting closely.
| Package | 0603 (1608 metric) — SMD surface mount |
| Forward Voltage | 1.8-2.6v |
| Brightness | 150mcd |
| Viewing Angle | 120 Degrees |
| Lens | Clear |
| Drive Current | 20mA typical |
Hand-solderable with a fine-tip iron and flux paste. Easier than 0402, still small enough for tight decoder and PCB layouts.
Common uses:
- Gaming console repair — Xbox 360/One, PS3/PS4, Wii, and Game Boy indicator LED replacement (iFixit community)
- Guitar pedal builds — Boss 2017+ models and modern stompbox PCBs use 0603 indicator LEDs (Freestompboxes, PedalPCB)
- Mechanical keyboard backlight repair — per-key indicator LEDs on custom PCBs (r/MechanicalKeyboards, Geekhack)
- N scale and HO scale DCC decoder lighting — headlights, interior lights, and function outputs
- Custom PCB indicators for ESP32/RP2040 projects, breakout boards, and open-source hardware designs
Also available: 0402 (smaller) · 0805 (larger)
Sold individually (1 LED per quantity ordered).
More Information
| Size | 0603 SMD |
|---|---|
| Color | Yellow/Gold |
| Luminosity/Brightness | 150 mcd |
| Forward Voltage | 1.8-2.6v |
| Current | 20mA |
| Wavelength | ~ 589 nm |
| Viewing Angle | 120 Degrees |
| Mount Style | SMD (Surface Mount Diode) |
| Lens Color | Clear |
| LED Brightness Class | Super/Ultra/Extreme |
| Documentation Link | Documentation: 0603 / 1608 Yellow / Gold SMD LED Datasheet / Specifications |
Customer Images
Share your photos of this product in action! Uploaded images require approval before display. Please do not include watermarks — watermarked images will be declined. By uploading, you agree that your images may be used as product photos, in tutorials, or related content. Customer photos may not exactly represent this product. Items shown may be modified, and LED colors may appear different due to the difficulty of capturing true light colors on camera.
