RGB - PLCC6/5050 12V LED Strip - Adhesive Backing - Water Resistant - 5m Roll / Reel
In stock
- SKU
- 5050RGB12VLEDSTRIPWATERRESISTANT
- Color
- Red/Green/Blue (RGB)
- Size
- 12v Strip - 5050 / PLCC6 - 10mm Width
Description / RGB - PLCC6/5050 12V LED Strip - Adhesive Backing - Water Resistant - 5m Roll / Reel
The Red/Green/Blue (RGB) 5050 LED Strip is built for color-changing RGB accent lighting — kitchen, bedroom, home theater, van build. Flexible 12v DC reel with 3M adhesive backing — peel, stick, and power on.
| Chip Size | 5050 |
| Operating Voltage | 12v DC |
| Color | Red/Green/Blue (RGB) |
| Power Draw | 72 Watts / 5m (meters) - 60mA / 5cm Section (doesn't consume max during operation) |
| Brightness | 270 - 300 Lumens / Meter |
| Waterproof | Indoor use (no waterproofing) |
| Backing | 3M adhesive — peel-and-stick |
| Cut Points | Every 3 LEDs at marked cut lines |
RGB control: requires a compatible controller (44-key IR remote or MagicHome WiFi recommended — sold separately). Each channel (R/G/B) is driven independently — mix to any of 16 million colors.
Installation notes:
- Clean the mounting surface with isopropyl alcohol before sticking for best adhesion
- Cut only at the marked scissor lines — cutting elsewhere breaks the circuit
- Power supply: Meanwell LRS-50-12 handles up to 4m of dense 5050 strip; LRS-100-12 for full 5m reels
- Indoor only — not waterproof; keep dry
- color-changing RGB accent lighting — kitchen, bedroom, home theater, van build
Sold individually (1 unit per quantity ordered).
More Information
| Size | 12v Strip - 5050 / PLCC6 - 10mm Width |
|---|---|
| Color | Red/Green/Blue (RGB) |
| LED Count | 300 LEDs / 5m (meters) - 3 LEDs / 5cm (one section) |
| Operating Voltage | 12v DC |
| Drive Mode | Constant Voltage (12v DC) |
| Flexibility | Flexible |
| Mount Style | 3M Adhesive Backing Tape |
| Current | 72 Watts / 5m (meters) - 60mA / 5cm Section (doesn't consume max during operation) |
| Dimensions | Width: 10mm Height: About 2.5mm Length: 5cm - 5m (meters) |
| Operating Temp. (Temperature) | Recommended Range = -20C - 50C (-4F - 122F) |
| Waterproof / Resistance | Yes - Water Resistant |
| Viewing Angle | 120 Degrees |
| Luminosity/Brightness | 270 - 300 Lumens / Meter |
| Wavelength | RGB (varied) |
| Resistor Built In | Yes |
| Additional Resistors Required | No |
